Username Post: 63 SS Console        (Topic#349499)
69_BOWTIE
Senior Member
Posts: 986

Loc: WYOMING,USA
Reg: 02-27-02
02-04-18 04:33 PM - Post#2723331

Scored a SS shift console this weekend, I have installed a 700r4 trans during my rebuild . I have no shifter for it so I was wondering if anyone has converted a different shifter to work with the console. I don't mind a little fab. work. I have nothing to go by or if its possible , I allways see used shifters at the swap meets and was curious . I don't like the LOKAR shifters for this app. and I have looked at the shift works shifter but kinda piching pennys here until I get my dash done. Thanks for all the Help

2001 Silverado 4X4
2005 FXDWGI
69 CHEVY Short Step
63 IMPALA 2/DR HRDTOP 327



This Forum is Sponsored by
1-800-IMPALAS  *  www.impalas.com
Visit Impala Bob's forum on ChevyTalk
Andy4639
Frequent Contributor
Posts: 1089

Age: 57
Loc: Liberty, SC
Reg: 08-06-16
02-04-18 07:30 PM - Post#2723355
    In response to 69_BOWTIE

I have never done one but I would think just buying a stock shifter and they make the OverDrive indicator for it.

https://www.impalaparts.com/64SIO/




1956 Bel Air - LT-1/4l60
1964 SS Impala -350 crate/powerglide
1967 Ramp truck - 350/ 4 speed
1971 C 10 - 6.0 LS / 4l80e 4:10 gears 30 years owner
94 Elderado
2000 S-10
2008 LTZ Tahoe
2011 Treverse



DZAUTO
Senior Member
Posts: 8473

Loc: Mustang, OK, USA
Reg: 12-25-99
02-04-18 08:46 PM - Post#2723365
    In response to Andy4639

I thought the correct shift pattern was
R 1 3

.. 2 4




69_BOWTIE
Senior Member
Posts: 986

Loc: WYOMING,USA
Reg: 02-27-02
02-04-18 09:20 PM - Post#2723373
    In response to DZAUTO

DZ I wish . Yeah I haven't been able to find a stock one.

2001 Silverado 4X4
2005 FXDWGI
69 CHEVY Short Step
63 IMPALA 2/DR HRDTOP 327



Andy4639
Frequent Contributor
Posts: 1089

Age: 57
Loc: Liberty, SC
Reg: 08-06-16
02-05-18 04:20 AM - Post#2723382
    In response to DZAUTO

  • DZAUTO Said:
I thought the correct shift pattern was
R 1 3

.. 2 4





The 700R4 wouldn't last to long shifting it like that!



1956 Bel Air - LT-1/4l60
1964 SS Impala -350 crate/powerglide
1967 Ramp truck - 350/ 4 speed
1971 C 10 - 6.0 LS / 4l80e 4:10 gears 30 years owner
94 Elderado
2000 S-10
2008 LTZ Tahoe
2011 Treverse



69_BOWTIE
Senior Member
Posts: 986

Loc: WYOMING,USA
Reg: 02-27-02
02-08-18 03:01 PM - Post#2723782
    In response to Andy4639

Where do the wires run to operate the dome light ? Do they tie into the rear sail panel lights or come from the dash straight down to under carpet into console .


2001 Silverado 4X4
2005 FXDWGI
69 CHEVY Short Step
63 IMPALA 2/DR HRDTOP 327



pvs409
"6th Year" Gold Supporting Member
Posts: 2115
pvs409
Loc: Sergeant Bluff, Iowa
Reg: 01-10-05
02-08-18 03:44 PM - Post#2723787
    In response to 69_BOWTIE

On a factory SS car the center SS console is a separate wiring harness that connects to the dome light harness in the kick panel area.

The SS console wiring is clipped to the floor in front of the front seat from the Kick panel to the center console between the seats. The harness as I recall plugs into the Hardtop wiring harness that runs up under(after running veritcally from the kick panel area )to the headliner (on the drivers side) back to both rear lights in the sailpanels. The passenger side of the harness crosses in the middle of the headliner.
I have a new American Autowire headliner wiring harness to the lights in the sailpanels -its left over from my 62 SS Hardtop---don't ask why
Paul

57 BelairHT 283/270hp 4 spd
62 ImpHT 327/300 4 spd
62 Imp CV SS 327/300HP 700R4
62 ImpHT SS 409/482 stroker 4 spd
62 Imp SS 409 - 5 spd Convertible under frameoff
Website http://paulstensland.com/
[image]http://chevytalk.org/sm/26453.jpg[/ima



gkralik3645
"4th Year" Silver Supporting Member
Posts: 184
gkralik3645
Loc: omaha
Reg: 12-05-13
02-08-18 04:41 PM - Post#2723793
    In response to 69_BOWTIE

My 63 has no dome light.

George




69_BOWTIE
Senior Member
Posts: 986

Loc: WYOMING,USA
Reg: 02-27-02
02-10-18 08:14 PM - Post#2723996
    In response to gkralik3645

Mine doesn't have one either, I wonder if there is an extra plug on the loom for one.So it should just be 1 off the door lights to the rear console light and then the glove box light piggy back's off that using the console door switch? I have seen an extension that says it comes off the NSS for the auto. What do I need to get my lights to work kinda looking for a plug and play

2001 Silverado 4X4
2005 FXDWGI
69 CHEVY Short Step
63 IMPALA 2/DR HRDTOP 327


Edited by 69_BOWTIE on 02-10-18 08:42 PM. Reason for edit: No reason given.


Impalaserg
Infrequent Contributer
Posts: 36
Impalaserg
Age: 41
Loc: Illinois
Reg: 03-07-12
02-13-18 11:17 AM - Post#2724262
    In response to 69_BOWTIE

http://www.shiftworks.com/kits.htm




gkralik3645
"4th Year" Silver Supporting Member
Posts: 184
gkralik3645
Loc: omaha
Reg: 12-05-13
02-13-18 01:52 PM - Post#2724279
    In response to 69_BOWTIE

I looked at the wiring diagram in the 63 shop manual and it doesn't show anything for the console. On my car, the rear light of the console does light up when a door opens so you may be correct about it being wired to a door switch. However the NSS can't be wired to the door switch because you usually shift with the door closed. I don't know about the front light of the console because mine doesn't work.

George
