Username Post: temp gauge not working        (Topic#294552)
2dr150
"8th Year" Silver Supporting Member
Posts: 415
2dr150
Loc: eastern S. C.
Reg: 07-16-06
03-09-13 02:18 PM - Post#2324445

Last of the restoration problems, I hope. Repairs is still underway on the wipers, heater fan not working, and now the temp gauge. Needle on the gauge has not moved since I got car running. I have replaced the sender and still doesn't move. I have checked hookups on back of gauge, they seem to be correct. Any ideas on what could be wrong. I really think the gauge is OK. Thanks, Tom
1957 bel air sport coupe
1962 impala ss
1957 2dr 150,owned 6 yrs
my chevys



This Forum is Sponsored by

bobsclassicchevy.com
acardon
Senior Member
Posts: 9780
acardon
Loc: DFW TEXAS
Reg: 03-25-05
03-09-13 02:41 PM - Post#2324456
    In response to 2dr150

  • Quote:
I have replaced the sender and still doesn't move.



Where is the needle sitting when key is on? If it on the cold side, temporiarly ground the wire at the sender terminal and it should go all the way to "hot". If it doesn't, check that the dark green wires are plugged togather in the plug near the ignition switch. See the box in the diagram to the left of the ignition switch where the dark green sender wires connect together under the dash. .... Link to diagram.
Don
66 Corvair (driving)
57 2dr HT (driving)
56 2dr HT (waiting to be restored)



2dr150
"8th Year" Silver Supporting Member
Posts: 415
2dr150
Loc: eastern S. C.
Reg: 07-16-06
03-09-13 09:19 PM - Post#2324596
    In response to acardon

Don, As I have mentioned before, I don't have a ballast. In my harness coming out near the w/s wiper motor there are two wires together which would normally go to the ballast(i think). I believe they are lt green but I don't have them connected to anything. Your thoughts.....Thanks for all your help. Tom
1957 bel air sport coupe
1962 impala ss
1957 2dr 150,owned 6 yrs
my chevys



acardon
Senior Member
Posts: 9780
acardon
Loc: DFW TEXAS
Reg: 03-25-05
03-09-13 09:41 PM - Post#2324601
    In response to 2dr150

As you can see in the diagram, the ballest resistor normally has a green and a tan wire on it. If they are connected together and the ballest removed, it will run fine. If it still has points, they won't last as long, but if it's been converted to a electronic distributor module it may not need the ballest resistor.
The temperature sensor dark green wire is a differnt circuit than the ballest wire and don't have anything to do with each other. The temperature wire does go through the firewall grommet in the same area though.
Don
66 Corvair (driving)
57 2dr HT (driving)
56 2dr HT (waiting to be restored)


Edited by acardon on 03-09-13 09:46 PM. Reason for edit: No reason given.


2dr150
"8th Year" Silver Supporting Member
Posts: 415
2dr150
Loc: eastern S. C.
Reg: 07-16-06
03-10-13 03:07 PM - Post#2324763
    In response to acardon

Acardon you are the man. The two green wires were not connected, they are now and the gauge is working. Thank you for your help. Tom
1957 bel air sport coupe
1962 impala ss
1957 2dr 150,owned 6 yrs
my chevys



nash_alex
Forum Newbie
Posts: 27
nash_alex
Loc: Boca Raton, FL
Reg: 05-07-13
05-13-13 05:48 AM - Post#2344772
    In response to acardon

I am having trouble finding out where the green wire goes coming out from the pigtail. The pigtail has 2 tan wires, one purple wire, one black wire in the pigtail connector, and one green coming out of the pigtail with a male connector on it. I have looked at the diagram, but I am having trouble reading as to where the green wire connects.
