Username Post: Power Seat-Heated seat Problems?!?!        (Topic#182894)
Bowyer
Member
Posts: 4

Reg: 02-22-08
02-22-08 01:55 PM - Post#1372269

I have a 2003 GMC Yukon (hope that is OK) and the heated seats on both sides are not working. On the driver seat, there is no power -, ie: seats won't move at all. Passenger side seat has no heat but power. I can't seem to find the fuse or whatever the problem seems tto be. Any help is much appreciated!!!

PS---Everything was working fine until a few days ago!


Low priced Genuine GM Auto Parts
arcticcat38
Member
Posts: 6

Reg: 01-16-08
02-22-08 04:24 PM - Post#1372352
    In response to Bowyer

check under the hood for the fuse.



Bowyer
Member
Posts: 4

Reg: 02-22-08
02-22-08 04:34 PM - Post#1372359
    In response to arcticcat38

Yeah--I checked in the maual and didn't see it labeled anywhere. Also checked in the side (interior) fuse box--manual seems to have dozens of fuses--but not the one I need.

A bit more specific information would help!


hick67
Member
Posts: 76

Age: 24
Loc: Edmonton, Alberta
Reg: 11-19-07
02-23-08 08:06 PM - Post#1373123
    In response to Bowyer

do the heated seat buttons light up and instantly shut off... or nothing at all?


Bowyer
Member
Posts: 4

Reg: 02-22-08
02-25-08 09:53 AM - Post#1374190
    In response to hick67

Hick67--no lights at all!


Bowyer
Member
Posts: 4

Reg: 02-22-08
02-29-08 03:55 PM - Post#1377635
    In response to Bowyer

Anyone? My seats are stuck in a bad spot and the heat isn't working!

Thanks--


BlueJeep
Member
Posts: 1

Reg: 03-04-08
03-04-08 08:31 AM - Post#1380122
    In response to Bowyer

I don't mean to hi-jack this thread, but I thought if any resolution is brought to this it would be nice to have them all in one thread. I have the opposite problem with the seat heaters in my 03 Suburban, the lights come on for about one second and then shut off automatically, both driver and passenger side.


prosecond
Newbie
Posts: 4

Reg: 05-21-08
05-21-08 07:20 PM - Post#1438426
    In response to BlueJeep

The lights for my heated seats come on for a few seconds and then shuts off. What is the problem and how do I fix it?


prosecond
Newbie
Posts: 4

Reg: 05-21-08
06-03-08 11:38 AM - Post#1447575
    In response to prosecond

Any one have an idea? The wiring under seat looks OK but the lights on the switch still just come on and then shut off.


prosecond
Newbie
Posts: 4

Reg: 05-21-08
06-20-08 11:47 AM - Post#1460451
    In response to prosecond

Help!


srt4
Senior Member
Posts: 205
srt4
Reg: 11-23-05
06-23-08 05:12 AM - Post#1461984
    In response to prosecond

From what I've seen is that if the lights come on then shut right off you've got a short in the wiring. If nothing happens like in the first post it should be a fuse issue.
2001 Silverado LS Ext. Cab 4x4 2004 Dodge SRT4



prosecond
Newbie
Posts: 4

Reg: 05-21-08
06-30-08 11:58 AM - Post#1467427
    In response to srt4

srt4,
Thanks for the reply. The lights do come on and then shut off right away. I assume a short. Could this just be a short in the heating element and that needs replaced or in the wiring?


scomo
Forum Newbie
Posts: 23
scomo
Loc: Tulsa
Reg: 06-03-08
10-28-08 06:28 AM - Post#1551739
    In response to prosecond

This has recently happened to me. I have a 2004 Thaoe. I read in the manual last night that there is a button you can press to turn the heated seats on and they will stay on only until the seat reaches a certain temperature. I wonder if this sensor is out of camber and needs to be reset? I read on another forum that in 2005 GM issued a patch or OBD2 scan to fix this. I guess you could call it an electronic update for your truck. Has anyone else heard of this? I wonder if this magical scan could fix all our problems...


scomo
Forum Newbie
Posts: 23
scomo
Loc: Tulsa
Reg: 06-03-08
12-05-08 02:37 PM - Post#1578510
    In response to scomo

Bump**


lkaskel
Contributor
Posts: 110
lkaskel
Loc: Westminster, Maryland
Reg: 01-02-08
12-08-08 09:33 AM - Post#1580144
    In response to scomo

As a part of troubleshooting can someone pull the fuse that would control the seats and when the correct fuse is pulled the seats/heated light will quit working. Then you can report to us what the correct fuse is called. I know sometimes the naming convention they use does not clearly ID what it is actually for. This would be a good step 1. I would be suprised if the seat control and seat heater would be on the same fuse though.
Larry

99 Z71 5.3
97 Malibu
94 K1500 Blazer
07 Rendezvous (daily ride)



lkaskel
Contributor
Posts: 110
lkaskel
Loc: Westminster, Maryland
Reg: 01-02-08
12-08-08 10:00 AM - Post#1580156
    In response to lkaskel

I just checked my manual (for my 99 NBS) and in the fuse block mounted in the drivers side edge on the dash it shows fuse 13 is for a few things including the power lumber seats and device A (I am unsure if this is a larger fuse or a relay) is for a few things including the 6-way power seats. In the fuse block under the hood there is a large fuse labled heated seats but in the manual it says "not used". I am looking at my manual electronically and my truck is not with me so I am unable to look at it.
Larry

99 Z71 5.3
97 Malibu
94 K1500 Blazer
07 Rendezvous (daily ride)



kcfd82
Lurker
Posts: 1

Reg: 12-24-08
12-24-08 02:07 PM - Post#1592026
    In response to lkaskel

Ok I have a question then, I have an 02 Yukon Denali and both of the front seat heaters don't work....But the switch turns on when I hit it and will stay lit till I turn the car off. The fuses are all good, so would it be the relays that are bad or the elements? Any ideas thanks


otisblkR1
Forum Newbie
Posts: 34

Reg: 06-29-08
12-26-08 08:10 PM - Post#1593275
    In response to kcfd82

Ok i will throw my hat in the ring, my 06 silverado is having troubles. the lights on the switches come on on both sides, the lower back portion works great, but the seat portion doesnt get "HOT" as it did only a week ago, its like its stuck on the low setting, this happend to both seats at the same time.. any thoughts ?


otisblkR1
Forum Newbie
Posts: 34

Reg: 06-29-08
12-30-08 09:40 PM - Post#1595842
    In response to otisblkR1

GO FIGURE ! truck goes into shop, the seats are not working, the tech gets the truck in the bay, they call me out and say "there working" im stumped, i put my hands on the seats and sure enuff both seats are toasty ! i leave the shop with a smile get a mile down the road and turn the seats on, No HEAT... GRRRRR got to be a pinched wire under there, before it was both seats not working, now its just the drivers seat. Im stumped. will call em back tomorrow and let em know whats happened.


scomo
Forum Newbie
Posts: 23
scomo
Loc: Tulsa
Reg: 06-03-08
12-03-09 12:54 PM - Post#1817084
    In response to otisblkR1

  • otisblkR1 Said:
GO FIGURE ! truck goes into shop, the seats are not working, the tech gets the truck in the bay, they call me out and say "there working" im stumped, i put my hands on the seats and sure enuff both seats are toasty ! i leave the shop with a smile get a mile down the road and turn the seats on, No HEAT... GRRRRR got to be a pinched wire under there, before it was both seats not working, now its just the drivers seat. Im stumped. will call em back tomorrow and let em know whats happened.



I have to resurect this one from the dead. Has anyone been able to diagnose the problem here? I'm on the verge of purchasing new heated seat switches and giving that a try -


Zeker
Senior Member
Posts: 452
Zeker
Loc: New Liskeard ON, Canada
Reg: 12-15-02
12-04-09 06:38 PM - Post#1817896
    In response to scomo

My 99 Tahoe manual says the seats won't heat up unless the seatbelt is buckled. So, there must be a switch in the latch assembly. Possible that it has poopoo the bed.

Brent.
05 2WD 1500HD Crew
99 2WD 4D Tahoe
'87 Harley FLHSS



BarryC
Forum Newbie
Posts: 4

Loc: Davidson, NC
Reg: 10-12-09
12-07-09 09:26 AM - Post#1819419
    In response to Zeker

Wanna trade seats? I couldn't get mine to STOP working. The @#$ things had a mine of their own and could come on and cycle thru the settings randomly. I could turn them off and in a few seconds they would be back on. The problem was that it was only like 60 degrees out and I didn't want or need the heated seats.


Scotts
Frequent Contributor
Posts: 1045
Scotts
Loc: McDonald, TN
Reg: 07-20-08
12-07-09 10:37 AM - Post#1819453
    In response to Zeker

  • Zeker Said:
My 99 Tahoe manual says the seats won't heat up unless the seatbelt is buckled. So, there must be a switch in the latch assembly. Possible that it has poopoo the bed.

Brent.



That would keep the srs systems lamp / warning on also.

The body controller has the ability to self diagnose the heated seat system. 03 Yukon for sure...

The switch has a TSB indicating improper switch replacement due to user error - not sure what that means except your not holding your finger correctly...

I would pull bcm codes and see if it holds the answer. Otherwise pinpoint testing, broken wires in door jambs, under the seat, power to the switch, etc.

99 Tahoe

NO WARRANTY EXPRESSED OR IMPLIED! I may be wrong, have in the past and will be in the future!



DenaliXL
Contributor
Posts: 133

Reg: 02-25-07
12-11-09 03:11 PM - Post#1822157
    In response to Scotts

To those that have the heated seat switch lights come on then shut off after a minute or so... had the same problemin my 2003... the D/S element was shorted. You could see it was burnt. At night with the seat cover off, you could see it sparking if you moved it a little. Easy fix -not uncommon. D/S normally wears faster than P/S. The two are wired together so when one shorts, they both trip the breaker.

Edited by DenaliXL on 12-11-09 03:12 PM. Reason for edit: No reason given.


chopermech
Forum Newbie
Posts: 1

Reg: 12-14-09
12-14-09 07:21 PM - Post#1824154
    In response to DenaliXL

  • DenaliXL Said:
To those that have the heated seat switch lights come on then shut off after a minute or so... had the same problemin my 2003... the D/S element was shorted. You could see it was burnt. At night with the seat cover off, you could see it sparking if you moved it a little. Easy fix -not uncommon. D/S normally wears faster than P/S. The two are wired together so when one shorts, they both trip the breaker.




I currently have this problem, can you elaborate about the heat element, it's location and removal? A pic might even be nice..



scomo
Forum Newbie
Posts: 23
scomo
Loc: Tulsa
Reg: 06-03-08
12-17-09 09:46 AM - Post#1825613
    In response to chopermech

Well guys,

This past week i bought a replacement door switch for my drivers heated seat. I pulled the door pannel off and replaced the old switch with the new one last weekend. I pressed the button and it lit up, but with the same result; it kicked right back off within a few seconds.

This is a picture of the switch i replaced:


When my switch light turns off, I always hear a clicking sound beneath my drivers seat. It leads me to believe (along with what i learned this last weekend) that the problem is with the heating element, below the seat. From what i understand, to access the element you have to pull back the seat covering. Is that correct? Could anyone elaborate?


DenaliXL
Contributor
Posts: 133

Reg: 02-25-07
12-18-09 03:44 PM - Post#1826389
    In response to scomo

  • Quote:
I currently have this problem, can you elaborate about the heat element, it's location and removal? A pic might even be nice..



The heating element is like a piece of fabric that sits under the leather. Its held in place front and back by what amounts to tape to the foam. The new one comes with it - peel and stick like a band-aid.

To change, you unscrew the seat control switches and plastic panel on the side of the seat. The switches or connectors unscrew from the inside of the panel also IIRC. With the switches out of the way, the leather is pulled off the seat cushion. Its held on by way of plastic channels that are part of the cover that sit over the edge of the metal frame. Pull the channel off the metal and up it comes to reveal the heating element. I didn't completely remove the cushion leather from the seat and left it attached in the back. I pulled the element up (ripping an insignificant amount of foam with it due to adhesive). The element wires snake through the back of the seat and simply plug into the truck harness. If you are looking underneath the seat, the connector is bright green. I used a long pick to pull the wires to where I could reach them with my hand. The key is to lay the new element as flat as possible when sticking the adhesive to the foam. The "right way" is probably to take the seat apart or at least to fully remove the leather from the cushion in order to get it perfectly flat in the back where the seat cushion and seat back come together but I was able to get it pretty flat just pushing it back with my fingertips then peeling the adhesive strip. Installation of the leather and switches is reverse of removal.

Its really a piece of cake job. Budget 30 minutes. The old one should look burnt up in spots which will confirm that its the issue. Element was like $90 through a friend in the industry.


bigtallcampbell
Forum Newbie
Posts: 1

Reg: 12-25-09
12-25-09 05:53 PM - Post#1830398
    In response to scomo

Same problem, but I think mine is the door switch. What was the part number and where did you get it from? Quick search of Ebay and amazon are pulling up empty.


Al_Brown
Forum Newbie
Posts: 3

Reg: 03-30-11
03-30-11 04:49 PM - Post#2069650
    In response to Bowyer

2011-03-30

I have a problem with my 2003 Tahoe (mileage: 89,000 miles) seat heater on the driver's side. It seems to have a mind of it's own.

The seat heater comes on by itself and cycles through all three settings; 3-lights, 2-lights, 1-light, all off and then repeats over and over; 1, 2, 3, all off.

This happens both while in motion and while stationary.

I removed and disabled the seat heater controls in the driver's side door panels. No joy and it keeps my bottom side HOT all the time.

The passenger's side seat operates perfectly normally.

In desperation, I removed the 25-amp CB to disable both the front (L and R) seat heaters and motors, but that also disables the seat adjust motors.

Does anyone know of why the left seat heater is going nutz?

Any inexpensive fixes?

Thanks!




hooper
Forum Newbie
Posts: 2

Reg: 04-03-11
04-03-11 07:23 PM - Post#2071522
    In response to Al_Brown

Al, I have the exact same problem with my driver side heated
seat, as you describe it, with my 2003 tahoe. Did you get
any clues as to what is causing this to happen? Thanks.
