Username Post: Need advice for 250 to 350 swap, 66 Impala        (Topic#143437)
MoparManiac
Member
Posts: 1

Loc: Suffolk, Virginia
Reg: 11-01-06
11-01-06 07:17 AM - Post#1027148

Greetings! MoparManiac here helping a friend turn wrenches on his Chevy. His '66 Impala came with a 250 I6 originally, but we're trying to put a 350 V8 with a 200R4? overdrive transmission into it's place. My friend is in the military and deploys for IRAQ next week!!! We're trying to get all parts together, correctly, before we start on this install so any help with this is greatly appreciated! The 250 was pulled lastnight, the 350 is built and sitting on a motor stand. He will be picking up the transmission, a flexplate, and an 1800-2200 stall converter today. Please tell us if the motor mount brackets are different, if the transmission mounts are different, what we will need there, etc. The more details the better so we can hopefully have it in there by the weekend. He's putting in a new radiator OEM for a 327 car, and keeping original power steering so we will need to deal with brackets on the motor as well, he currently has no brackets. Also, wants to move alternator to passenger side from drivers side. Will be using a stock points type distributor with pertronix kit for that stock look. Please help us with the mounts and bracket info and anything we may be overlooking. Anything helps, because time is the issue here! Thanks for understanding, and thanks in advance for your help. I will check often. Regards, MoparManiac.


This Forum is Sponsored by
1-800-IMPALAS  *  www.impalas.com
Visit Impala Bob's forum on ChevyTalk
leon phelps
Valued Contributor
Posts: 3438
leon phelps
Loc: Croydon Manor, PA
Reg: 06-04-05
Re: Need advice for 250 to 350 swap, 66 Impala
11-01-06 08:11 AM - Post#1027149
    In response to MoparManiac

I think the motor mounts will be the same, but you will need to fabricate a trans mount.

You can but trans mounts to do this, but they are expensive..
Metallica Fuel



raycow
Honored Member
Posts: 18643

Age: 71
Loc: San Francisco, CA
Reg: 11-26-02
Re: Need advice for 250 to 350 swap, 66 Impala
11-01-06 11:21 AM - Post#1027150
    In response to leon phelps

The 200-4R rear mount is the same distance from the bellhousing face as a TH400, and the TH400 was a factory option on these cars. See if you have another set of holes farther back to mount the crossmember.

Ray
Bacon is the gateway drug for vegetarians - Bridget Lancaster



leon phelps
Valued Contributor
Posts: 3438
leon phelps
Loc: Croydon Manor, PA
Reg: 06-04-05
Re: Need advice for 250 to 350 swap, 66 Impala
11-01-06 11:39 AM - Post#1027151
    In response to raycow

Thanks for the info Ray. I have a 66 ss convetible that I will eventually be doing the same with. You just saved me some G&A
Metallica Fuel



mjc1
Senior Member
Posts: 1323
mjc1
Loc: Burlington Ontario Canada
Reg: 09-15-04
Re: Need advice for 250 to 350 swap, 66 Impala
11-01-06 11:39 AM - Post#1027152
    In response to MoparManiac

The TV cable for the 200R will need a "little" thought.

BowtieOverdrives TV Tech.
1967 Grande Parisienne 4DR HT
My Flickr page




mn65bis
Senior Member
Posts: 756
mn65bis
Loc: Oakdale MN
Reg: 10-31-06
Re: Need advice for 250 to 350 swap, 66 Impala
11-01-06 11:46 AM - Post#1027153
    In response to MoparManiac

I put a big block in a 65 bisc. That was a 6cyl. and had to change the mounts on the frame.



raycow
Honored Member
Posts: 18643

Age: 71
Loc: San Francisco, CA
Reg: 11-26-02
Re: Need advice for 250 to 350 swap, 66 Impala
11-01-06 11:48 AM - Post#1027154
    In response to leon phelps

Quote:

You just saved me some G&A



What is G&A - or aren't you allowed to say it on the board?

Ray
Bacon is the gateway drug for vegetarians - Bridget Lancaster



leon phelps
Valued Contributor
Posts: 3438
leon phelps
Loc: Croydon Manor, PA
Reg: 06-04-05
Re: Need advice for 250 to 350 swap, 66 Impala
11-03-06 01:35 PM - Post#1027155
    In response to raycow

grief and aggravation
Metallica Fuel



427SS65
"10th Year" Platinum Supporting Member & Moderator
Posts: 13362
427SS65
Age: 68
Loc: St. Louis, MO
Reg: 12-11-03
Re: Need advice for 250 to 350 swap, 66 Impala
11-03-06 05:02 PM - Post#1027156
    In response to mn65bis

Like mn65bis said, you will have to find a pair of motor perches (towers) for any 65 V8 full size car. They are on eBay every now and then for about $30, or just go to a junkyard and unbolt a set.

You might need the 4" radiator spacer to get the radiator closer to the fan or you can use a long water pump.

Don't start until you have at least the motor perches. You can't use the 6 cylinder ones! (all V8's were the same, small or big block).
Tom 65-70 Full Size Team Moderator

View My Photos Here

65 Impala SS Tahitian Turquoise



raycow
Honored Member
Posts: 18643

Age: 71
Loc: San Francisco, CA
Reg: 11-26-02
Re: Need advice for 250 to 350 swap, 66 Impala
11-03-06 05:29 PM - Post#1027157
    In response to leon phelps

Quote:

grief and aggravation



Thank you, Leon. As always, I leave here wiser than when I came in.

Ray
Bacon is the gateway drug for vegetarians - Bridget Lancaster



MI2600
Senior Member
Posts: 760

Loc: N. Muskegon, MI
Reg: 05-30-03
Re: Need advice for 250 to 350 swap, 66 Impala
11-03-06 06:41 PM - Post#1027158
    In response to raycow

We did this swap on our '67.

Yes, the motor perches are different and located in a different set of holes on the crossmember.

The 250 radiator will work in a pinch, but doesn't provide the cooling of a V8 style. You should also haunt Ebay for a shroud although your time is short.

You will have to "massage" the engine bay harnesses to work on the 350. With the pertronix unit you will have to replace the resistor wire in the engine harness with normal wire to get a full 12v.

I believe the full-size cars came with double perches on the frame for the trans crossmember. I believe the front ones fit the powerglide, 4-speed, and 350TH. The rear ones are for the 400 and will work with your 200R4.

Our 250 came with a low-performance starter. You'll need a higher output starter which should be available at a junkyard. You can tell if you have a high performance starter by looking at the rear of the solenoid. If it has a brass "tube" between the solenoid and the rear starter motor connection then you have a high performance model.

If you need further help let me know.
'67 Biscayne
'72 El Camino
'86 El Camino
