Username Post: Water Leak - Drivers Side Floor by Kickpanel        (Topic#115833)
chucker
Senior Member
Posts: 426

Loc: NJ
Reg: 11-01-05
11-01-05 06:55 PM - Post#808015

Have a 84 C-10 and after a nice rain, water magically appears on the cab floor on the very left hand side (right by your left foot). More specifically, the water is in the area where the cab floor meets the kick panel. Any help on the source of the leak is appreciated. Thanks
'84 C-10 SWB, L6 250, 3 speed saginaw
'87 C-10 LWB, V8 305, 700R4 ( recently parted with, may she fine peace after 225,000 miles ).
'84 Trans Am, 355, T-5

If you are going to do it, do it once and do it right...Or don't do it at all.



N8sToolz
Very Senior Member
Posts: 2315
N8sToolz
Age: 28
Loc: N 42┬░ 53.290' W71┬░ 34.1...
Reg: 10-23-03
Re: Water Leak - Drivers Side Floor by Kickpanel
11-01-05 07:33 PM - Post#808016
    In response to chucker

Either the windsheild or at the seam itself, im not sure if water is supposed to be running along the outside of the cab on that particular position, but i have the same exact leak on my truck that i just now found. get it wet and look under with a flashlight you will see it running.
1982 Chevy K20 Converted from C20.
355/700R4
2002 Yamaha XVS1100CL VStar
2002 S10 2WD



McLeod
Member
Posts: 237
McLeod
Loc: North Carolina
Reg: 01-10-05
Re: Water Leak - Drivers Side Floor by Kickpanel
11-02-05 09:11 AM - Post#808017
    In response to chucker

If you don't see it from under the dash, pull the panel between the windshield and rear of hood & look closely for some rust holes. Unfortunately, it isn't uncommon to have some corrosion there, especially in the "crease" area where the dash and firewall join.
McLeod -- 1999 Tahoe LT, '03 2500HD Ext. Cab.



WVTOMMY
Senior Member
Posts: 183

Loc: FALLING WATERS WV
Reg: 01-01-04
Re: Water Leak - Drivers Side Floor by Kickpanel
11-02-05 02:25 PM - Post#808018
    In response to McLeod

check for the leak on fire wall there is a rubble grommet where some wires go through.


chucker
Senior Member
Posts: 426

Loc: NJ
Reg: 11-01-05
Re: Water Leak - Drivers Side Floor by Kickpanel
11-02-05 07:08 PM - Post#808019
    In response to N8sToolz

Do you have this leak on the driver's side only? No water is coming through on my passenger side. I did notice in the day time some water stains from the bottom of "fresh air vent" on the driver's side (inside the cab). Will continue to investigate...Thanks
'84 C-10 SWB, L6 250, 3 speed saginaw
'87 C-10 LWB, V8 305, 700R4 ( recently parted with, may she fine peace after 225,000 miles ).
'84 Trans Am, 355, T-5

If you are going to do it, do it once and do it right...Or don't do it at all.



WVTOMMY
Senior Member
Posts: 183

Loc: FALLING WATERS WV
Reg: 01-01-04
Re: Water Leak - Drivers Side Floor by Kickpanel
11-03-05 02:59 PM - Post#808020
    In response to chucker

YES ITS ON DRIVERS SIDE ONLY PULL UP MAT SHOULD BE DAMP MY OTHER SIDE IS DRY.


Anonymous

Re: Water Leak - Drivers Side Floor by Kickpanel
11-03-05 06:14 PM - Post#808021
    In response to chucker

On my old 83 I found the firewall was cracked where the e-brake pedal bolts go through the firewall, there was also some rust in that area.


chucker
Senior Member
Posts: 426

Loc: NJ
Reg: 11-01-05
Re: Water Leak - Drivers Side Floor by Kickpanel
11-04-05 06:59 AM - Post#808022
    In response to WVTOMMY

OK in the daylight now everything in the firewall area seems sounds, sealed up and no rust.

Interestingly enough, inside the truck on the flor the rust starts right below the vent door....So, with the hood closed and the hose running on the windshield, the water runs down the windshield under the cowl panel in the water drain area (where the wipers are). Stop the hose and open the fresh air vent and everything behind it is wet. Perhaps the gasket is gone on the air vent door, but I am going to remove the kick panel to check out the setup and how the water is running.
'84 C-10 SWB, L6 250, 3 speed saginaw
'87 C-10 LWB, V8 305, 700R4 ( recently parted with, may she fine peace after 225,000 miles ).
'84 Trans Am, 355, T-5

If you are going to do it, do it once and do it right...Or don't do it at all.



Slurfi
Senior Member
Posts: 413
Slurfi
Loc: Lappland, Sweden, Europe
Reg: 03-22-04
Re: Water Leak - Drivers Side Floor by Kickpanel
11-04-05 10:01 PM - Post#808023
    In response to chucker

Seen that leakage on my C10 and heard of others with
same wet floor problem, so please post your solution
when you are done.
TIA
1950 Chevrolet Fleetline 2dr
http://img102.imageshack.us/img102/4316/cheva50cmm ...
GMC 1500 2006, Suburban C10 1978



Petroholic
Contributor
Posts: 839
Petroholic
Loc: Moses Lake, Wa.
Reg: 08-12-05
Re: Water Leak - Drivers Side Floor by Kickpanel
11-05-05 03:40 AM - Post#808024
    In response to chucker

I too have the same problem on my 81. My windshield seal is pretty much toast, so I just assumed that was the problem. Time for a little deeper investigating.




chucker
Senior Member
Posts: 426

Loc: NJ
Reg: 11-01-05
Re: Water Leak - Drivers Side Floor by Kickpanel
11-05-05 04:37 PM - Post#808025
    In response to

OK...today I went all out with the hose (drivers side windshield and cowl area). The water enters the top of the fresh air drain (where the wiper transmission is and flows down through a passage that you cannot really see inside (but this is where the fresh air vent inside the cab gets the air) and I could actually see the water getting through the fresh air vent door from around certain areas of the outer rubber seal. The door also does not to seem to seal very well either but that could be the result of age, etc.

Since the fresh air vent door and lever are integrated into the kick panel, I tried taking out the kick panel but you need to remove the e brake mechanism from the firewall. I found this out after removing all the 7mm screws and trying to get the kick panel out but it actually goes into the metal air passage almost 1 inch. Anyhow I figured even if I get it out, the water would still get through the fresh air vent seal and I have not found anyone who sells these things...

I checked the firewall, e-brake bolts, looked for rust, cracks, etc. All of these connections still have the Armour undercoat from 1984 on them in very good shape. Water was definitely coming in around the rubber seal on the fresh air vent, coming to the bottom, and then dripping onto the plastic kick panel, then eventually the metal portion, finally making its way to the floor.

My Solution...Don't know yet and giving it some thought...but I wanted to post this out there for everyone to see. If you have ideas or can duplicate please let know.

How about just stuffing the thing with a rag...After all it is plastic and that does not rust
'84 C-10 SWB, L6 250, 3 speed saginaw
'87 C-10 LWB, V8 305, 700R4 ( recently parted with, may she fine peace after 225,000 miles ).
'84 Trans Am, 355, T-5

If you are going to do it, do it once and do it right...Or don't do it at all.



N8sToolz
Very Senior Member
Posts: 2315
N8sToolz
Age: 28
Loc: N 42┬░ 53.290' W71┬░ 34.1...
Reg: 10-23-03
Re: Water Leak - Drivers Side Floor by Kickpanel
11-06-05 08:54 AM - Post#808026
    In response to chucker

IN my 82 water is comming down through the windsheild gasket and somehow seeping through where the dash firewall and windheild meet, i havent pulled the dashpad to get a closer look yet. The runs right down the firewall, cuts the corner at the right side wall of the cab then under the vent and right down the bottom to the floor.

The drivers side has got me kind of confused now, From when i did the floors in my truck there is a seam on the front of the floor where the left side kick panel and old floor and new floor meet there is a hole where i couldnt fil in with the welder and have been meaning to fill it in with something else. Now being that it is overlapped, facing 45 degrees down and the water having to move UP to get into the truck has really got me guessing. Im thinking its comming along where the fender gasket should be as i dont think i have any. So i will try to reseal the windsheild ( they sell this stuff in LMC too i beleive that you put into where you think is leaking and it flows in like water bu sets and seals , the stuff works awsome ive used in on a taurus before with great luck.) And replace both sides fender gaskets and see where that goes. I have a cab out back and i was studying it the other day and it looks as if any water that comed off the roof, will flow forward, especially when not moving, down the A-Pillar, along that seam where the housing for the vent door and the cab door frame meet where if you look very closely there arent connected very well, just kind of pinched together then down to the rocker and back to where it will drip off. Now i think that gasket is there to keep the water from entering that chamber that the vent door is in. and if the water continues straight down into my floor area where commign from that angle it wont have to go up as much but still end up snaking though some how. I dont think i did a bad job especialy for a first time but will definately learn from my mistakes. I htink those gaskets will help you out with your problem comming in through the vents.
1982 Chevy K20 Converted from C20.
355/700R4
2002 Yamaha XVS1100CL VStar
2002 S10 2WD



3500
Member
Posts: 2

Reg: 06-18-04
Re: Water Leak - Drivers Side Floor by Kickpanel
01-01-06 03:01 PM - Post#808027
    In response to N8sToolz

I just picked up an '86 3+3 and guess what? The floor is wet. both A piilars have 18" of rust about a 1/4" wide. The seam at the roof and second pillar where it looks to be crimped together looks wet and rusted leading to the weatherstrip. I am suspicious the trim peaces above each door are leaking? Anyone come up with any other solutions?


WVTOMMY
Senior Member
Posts: 183

Loc: FALLING WATERS WV
Reg: 01-01-04
Re: Water Leak - Drivers Side Floor by Kickpanel
01-02-06 12:00 PM - Post#808028
    In response to 3500

im thinkin about just pulling up floor mat and sealing floor with some kind of liner.what do you guys think?


Douglas Ferguson
Senior Member
Posts: 378
Douglas Ferguson
Loc: Virginia
Reg: 09-12-04
Re: Water Leak - Drivers Side Floor by Kickpanel
01-02-06 12:43 PM - Post#808029
    In response to WVTOMMY

I would just try to find the leak and use your energy fixing that. Mine does the same thing, but my floor has rust holes all in it so the water just goes on the pavement! :O
66 Chevy C-10 SWB Stepside (project)
78 Chevy C-10 (Sold in 2009)
